Interactive SVG Maps with Vue

In a recent project, I needed to create an interactive map of Spain where each province was an element that could be hovered over and clicked.

I was working on the project using Nuxt.js and therefore Vue, so I decided to create a component that would encapsulate the graphical generation of the map and emit the corresponding events.

The first thing we need is the map in SVG format. Not just any map will do; it must be a map where each province is in a path and is correctly labeled. For example, we can use this one, which is free for both commercial and personal use.

If we open it, we see that it meets the condition of each province being in a path, and it also has metadata such as the province name.

<path id="ESP5840" name="Pontevedra" d="M451.9 ...." >

The next step is to convert that SVG to JSON to make it easier to handle with JS. I used this tool: https://www.freeformatter.com/xml-to-json-converter.html#ad-output, although there are libraries to perform the conversion “on the fly” from JS.

This will leave us with something like this:

To convert this information back into an SVG that we can manipulate, I used svg.js

The strategy consists of regenerating the SVG from the Vue component while adding the necessary events. To do this, once the component is mounted and using svg.js, we create a path for each province. This path is defined by the @d key of the JSON we generated from the SVG.

 generateMap() {
   const svgContainer = svg(this.id)
     .size("100%", "100%")
     .viewbox(0, 0, 1000, 891);
   provinces.forEach(pathObj => {
     this.generatePath(svgContainer, pathObj);
   });
 },
 generatePath(svgCont, pathObj) {
   const attrs = {
     fill: "transparent",
     stroke: "#28586c",
     "stroke-width": 1,
     title: pathObj["@name"],
     "map-id": pathObj["@id"]
   };

   const province = svgCont.path(pathObj["@d"]).attr(attrs);
 }

If you notice, we tell the SVG we created to occupy 100% (both width and height) of a viewbox whose size is defined by the original SVG. This defines the actual size of the SVG and which part will be visible; that is, if we draw an element beyond 1000x891, it won’t be seen because it’s outside the viewbox. However, the SVG is fully responsive; in other words, the viewbox size does not have a 1

relationship with the actual display.

As seen in the example, we create a path for each province. Now we need to provide it with interactivity so it can respond to a click.

...
const province = svgCont.path(pathObj["@d"]).attr(attrs);

province.click(e => {
  const mapId = e.target.attributes["map-id"].value;
  const title = e.target.attributes.title.value;
  this.$emit("mapClick", { mapId, title });
});
...

We simply emit a component event passing the ID and the name of the province, so that we can handle that click outside the component.

And this is the final result.

I have left the complete example on codesandbox.io
