Sergio Carracedo Sireno Grid: A lightweight CSS Grid system based on Grid Layout
CSS Grid Layout is a W3C standard that was brought to webkit and blink by Igalia, a company based in Galicia with programmers all over the world. We also had the honor of organizing a talk [Video] by one of the developers responsible for implementing CSS Grid Layout in Chromium/Blink and Safari/Webkit: Manuel Rego
Those of us who have been doing web layouts for a long time (a very, very long time) will remember an era when layouts were made using tables. Why? Because most web designs can be sliced into square or rectangular areas or zones, something that tables allowed at the time. With the arrival of the semantic web and CSS improvements, table-based layout was marked as a bad practice (which it was). CSS Grid Layout is “like” going back to table layouts but doing it right. I won’t go into too much detail, but table layouts were defined with tags, and here we define them with stylesheets.
Why?
One fine day, over a year ago, a web layout project fell into my hands, but in this case, it had a requirement that was quite unusual at the time: the layout had to be based on CSS Grid Layout. I had been using Bootstrap for column layouts for a while, as I find it very convenient to be able to define sizes for each “block” according to the screen size, and I didn’t want to lose this. So, I decided to create a grid system similar to/inspired by Bootstrap’s, but instead of using floating <div>s, as in Bootstrap 3, or flexbox, as in Bootstrap 4, I would use CSS Grid Layout.
Once this project was finished and seeing that this tool worked reasonably well, I decided to use it in more projects and finally share it with the community, releasing it at the beginning of this year.
That’s how Sireno Grid was born, with a name inspired by one of the statues that is, in my opinion, one of the ugliest in my city (Vigo), but at the same time, one with the most personality.
Goal
Sireno Grid has a simple goal: to serve as a responsive grid structure so you can create your layout simply—no buttons, badges, etc… just the grid, the “margins,” and the embedding of elements responsively.
As I mentioned, Sireno Grid is inspired by Bootstrap, and therefore I have used more or less the same class names with the same functions, so that switching from one to the other is easy. The main change is using the .grid-row class instead of .row to define the row; I did this so that both “frameworks” could be used together if necessary.
Breakpoints
The defined breakpoints are these (defined in an SCSS variable):
$grid-breakpoints: ( xs: 0, lxs: 576px, sm: 768px, md: 992px, lg: 1200px ) !default;
The containers
One thing I always had to modify or add on top of Bootstrap was the containers. By default, Bootstrap 4 only has two containers: a fluid one that takes up 100% of the browser width and a fixed one that takes on different sizes depending on the breakpoint used.
In none of my projects did this fit 100%. The one that fit best was a fluid container but with a maximum size. Therefore, Sireno Grid has a ‘.container-fluid’ that adjusts to 100% of the viewport, and a ‘.container-fluid-1920’ and a ‘.container-fluid-1440’ that adjust to 100% of the viewport with a maximum of 1920px and 1440px respectively.
The gutters or grid-gap
By default, .grid-row establishes a space between columns or “gutter” of 15px, but sometimes we need that gap not to exist. For this, I have created a collection of classes applicable to each column that disable that gap as follows:
.no-gutters => to remove spaces on both sides across all breakpoints.
.no-gutter-[xs|lxs|sm|md|lg] => to remove spaces on both sides from the indicated breakpoint onwards.
.no-gutter-[left|right] => to remove the space on the indicated side across all breakpoints.
.no-gutter-[left|right]-[xs|lxs|sm|md|lg] => to remove the space on the indicated side from the indicated breakpoint onwards.
As a technical note, gaps between columns do not use ‘grid-column-gap’ as it might seem logical, since that sets a fixed gap for all columns, making it impossible to specify one gap for two columns and a different one for others.
Column filler or Col filler
Surely on some occasion it has happened to you that around a container you had to put a different background on each side (either a color or an image); if this has happened to you, .grid-filler is designed for you.
As you will see on the Sireno Grid examples page, the layout for this is very simple and allows for responsive behavior.
Flexbox fallback
Unfortunately, not all users update their browsers (either because they can’t due to technical limitations or corporate policies, or because they simply don’t), so it was a requirement to establish a fallback for Sireno Grid features to flexbox for those browsers that do not implement the Grid Layout standard. Hopefully, we can remove this fallback when Grid Layout is more widespread.
Other features
I’ve left other features for you to check on the Sireno Grid website itself, where they are explained with usage examples.
Additionally, the website explains how to use Sireno Grid in your project (using NPM, for example) and shows examples (code included) of the features already mentioned.
I’m also linking a lightning talk I gave about Sireno Grid at a PHPVigo meetup.
Acknowledgements
I would like to thank Pedro Figueras for the logo design and BrowserStack for providing a license to use their tool for testing across multiple browsers.
